SD50432XA-HNR 4MP PTZ Wizsense without IR 32x optical zoom, incl. wall mount and power supply
WizSense represents the advanced AI algorithms Dahua uses in this camera series. By applying these algorithms, this camera is able to distinguish between people and vehicles. All other objects that do not match the AI-based algorithm, for example animals, shadows or trees, are filtered out. Cameras from the WizSense series are equipped with Starlight technology for optimal performance in low-light situations. The PTZ camera features PFA that allows the camera to already focus while operating the camera so it always gives a sharp image.
In addition, this PTZ uses WizSense technology for Auto tracking. Auto tracking is a technology where the PTZ camera automatically zooms in on a detected object and then tracks it according to the set paramters. Thanks to WizSense technology, this PTZ camera is better able to distinguish vehicles and people from other objects, making this generation auto-tracking camera a lot more accurate.
Specificaties:
| Camera | Number of image sensors: | 1 |
| | Optical/Thermal: | Optisch |
| | Beeldsensor: | 1/2.8 |
| | Resolutie: | 2560 x 1440 |
| | Number of pixels: | 4MP |
| | Minimum illumination strength (in colour): | 0.005 Lux |
| | Minimum illumination strength (LED on (black/white)): | 0 Lux |
| | Verlichting: | No |
| | LED On/Off (Day/Night): | Auto/Manual |
| | Shutter speed: | 1/1s ~ 1/30000s |
| | Noise reduction: | 2DNR, 3DNR |
| | Video Output: | No |
| Lens | Lens type: | Motorzoomlens |
| | Iris: | Auto Iris |
| | Focal Distance: | 4.9mm ~ 156mm |
| | Maximum opening: | F1.35 ~ F4.4 |
| | Horizontal aperture angle: | 61.6° ~ 2.1° |
| | Vertical opening angle: | 35.1° ~ 1.3° |
| | Focus control: | Auto/Manual |
| Video | Stream capability: | 3 streams |
| | Video compression: | H.264, H.264 +, H.264 B, H.264 H, H.264 M, H.265, H.265 +, MJPEG |
| | Frames per second (Main stream): | 25fps @2560 × 1440 |
| | 2nd stream: | 25fps D1: 720 x 576 |
| | 3rd stream: | 25fps @1280 × 720 |
| | Bitrate: | H.264: 3 Kbps-20480 Kbps, H.265: 3 Kbps-20480 Kbps |
| | Dag/Nacht: | Auto (filter), Colour, Black/White |
| | Light compensation: | BLC, HLC, WDR(120dB) |
| | Digital zoom: | 16x |
| | Optical Zoom: | 32x |
| | |
| | Smart Functions: | AI Perimeter Protection |
| | | AI Motion detection |
| | | Auto-track 2.0 |
| | | Face Detection |
| | | Object Abbonded/Missing |
| | Electronic Image Stabilisation(EIS): | Yes |
| | Defog: | Yes |
| | Privacy masking: | Yes |
| Audio | Built-in microphone: | No |
| | Audio input: | Yes |
| | Audio Output: | Yes |
| | Audio Compression: | AAC, G.711 A, G.711 MU, G.722.1, G.723, G.726, G.729, PCM |
| Netwerk | Ethernet: | RJ-45 (10/100Base-T) |
| | Storage option SD card: | Yes |
| | Maximum Storage Capacity SD card: | 256GB |
| Interface | RS-485: | No |
| | Alarm: | Yes |
| | Number of channels in: | 2x |
| | Number of channels out: | 1x |
| Elektrisch | including power supply: | Yes |
| | Voeding: | 24V DC, PoE +(Type IEEE 802.3at) |
| | Max Consumption: | Max: 16W |
| Omgeving | Operating temperature: | -40°C ~ 70°C |
| | Water resistance: | IP67 |
| | Vandal resistant: | IK10 |
| Algemeen | Accessories included: | 1x PFB300S Wall Mount Bracket, 1x PFA110 Mount Adapter,1x DC24V/2.5A Power Adapter |
| Constructie | Materiaal | Metal |
| | Diameter | Ø253mm |
| | Height | 186mm |
