Hikvision DS-7608NXI-K1 8-channel 4K NVR with HDMI, without PoE, and with 1 SATA port.
The Hikvision DS-7608NXI-K1 Network Video Recorder is an 8-channel Acusense recorder capable of supporting 8 IP cameras, which can be connected using your own PoE network switch. The NVR features Acusense, a technology that enables the recorder to recognize and record people and/or vehicles on all connected cameras. This reduces unnecessary recordings, such as footage of leaves blowing in the wind. The recorder features an HDMI output for connecting to a TV or monitor, a network output for connecting to the network or app, and 1 SATA port for a hard drive (not included as standard; select below)
Hikvision AcuSense NVR: 8-channel IP cameras up to 12MP 4K, classification of people and vehicles for motion detection (MD2.0) across 8 channels, quick target search, and 1-channel facial recognition. (video stream) or 4-channel facial recognition with photos.
Specifications:
- Intelligent analytics
- On-device AI – Face Recognition, Perimeter Protection, Motion Detection 2.0
- AI via camera—Face recognition, perimeter security, motion detection 2.0, ANPR, VCA
Motion detection 2.0 - Per device—All channels, 4 MP (up to 8 MP when Enhanced SVC mode is enabled) video analytics for person and vehicle recognition
- Per camera - All channels
Perimeter protection - Per device: 2-channel, 4 MP (HD network camera, H.264/H.265) video analytics for person and vehicle recognition to reduce false alarms
- Per camera—All channels
Video and audio - IP video input - 8 channels
- Inbound bandwidth - 80 Mbps
- Outbound bandwidth - 160 Mbps
- HDMI output—1-channel, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
- VGA output - 1-channel, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
- Video Output Mode - HDMI/VGA Independent Output
- CVBS output: N/A
- Audio output - 1-channel, RCA (2.0 Vp-p, 1 kΩ, using the audio input)
- Two-way audio - 1-channel, RCA (linear, 1 kΩ)
Decoding - Decoding Format: H.265/H.265+/H.264+/H.264
- Recording resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Playback - 8 channels
Decoding capabilities -
AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps) - Stream type - video, video and audio
- Audio compression - G.711 ulaw/G.711 alaw/G.722/G.726/AAC
Network - Remote connection - 128
- API - ONVIF (Profile S/G); SDK; ISAPI
- Compatible browsers: IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 or higher
- Network protocol - TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- Network interface—1 RJ-45 10/100/1000 Mbps auto-negotiating Ethernet interface
- SATA - 1 SATA interface
- Capacity - Up to 10 TB
- USB Interface -
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 2.0
